The FB4 is Pangolin’s ethernet-DAC.
Like the FB3 it comes with “Quickshow” but can also be attached to a Beyond license file.
The FB4 is meant to be integrated into laser projectors and therefore offers also slave boards for ILDA in/trough and DMX in/through.
Shows and single laser frames/animations can be saved on a micro SD card. They can then be triggered by DMX, ArtNet, time code or stand-alone.
The integrated OLED display offers all known laser adjustments like size, brightness, and other settings.
|Resolution of x/y-axis||12bit each|
|Resolution of R, G, B, C, M, Y||12bit each|
|Output speed||60kpps (Beyond), 40kpps (Quickshow)|
|via Quickshow/Beyond, OLED display|
|Operation modes||- Beyond/Quickshow streaming|
- DMX (optional)
- ILDAin (optional)
- ArtNet timecode
- Test mode
|Firmware updates||via Quickshow/Beyond (network)|
|Safety features||direct output for shutter, SafeGuard|
|Compatible software||Quickshow, Beyond|
Article in Shop
Network-ILDA Interface with optional breakout boards.
This product is unavailable.
470,00 €(MwSt. excl.)
